EGP2-X401

PCIe 2.0 compliant. RS-232/422/485 mode configurable by software
4800 to 3Mbps serial data rate (RS-232 921.6Kbps) serial data rate. 16C550 compatible. 256-byte FIFOs
Alternative vertical or horizontal connector
Full RS-232 functions with DB9 connector

附件下载

EGP2-X401



产品特色



  • PCIe 2.0 compliant. RS-232/422/485 mode configurable by software
  • 4800 to 3Mbps serial data rate (RS-232 921.6Kbps) serial data rate. 16C550 compatible. 256-byte FIFOs
  • Alternative vertical or horizontal connector
  • Full RS-232 functions with DB9 connector
  • Termination resistor enabled/disabled by DIP switch
  • Complies with EN61000-4-2 (ESD) Air-15kV, Contact-8kV
  • Industrial temperature -40 ºC to 85 ºC
  • 30μ” golden finger, 3-year warranty
  • Industrial design, manufactured in innodisk Taiwan






规格:

Module NameEGP2-X401
Module TypeM.2 to four RS-232/422/485 Module
FunctionSerial
Form FactorM.2 2242-B-M
Input I/FPCI Express 2.0 x 1
Output I/FRS-232/422/485
Output connectorDB-9 x 4
TDP0.58W (3.3V x 176mA)
Dimensions (W x L x H/mm)Vertical: 22 x 42 x 6.45
Horizontal: 22 x 42 x 7.65
TemperatureOperation: W/T temp: -40°C ~ +85°C
Storage: -55°C ~ +95°C
EnvironmentVibration: 5G @7~2000Hz
Shock: 50G @ 0.5ms
NotesPlease download driver from MyInnodisk website.
Windows: XP(32 bit), 7(32/64 bit), 8/8.1(32/64 bit), 10, WES7, CE7.0
Linux: Kernel 2.6.x and above.(We can provide Linux source for modification.)

产品料号:

P/NDescription
EGP2-X401-W1Vertical connector, Wide Temp.
EGP2-X401-W2Horizontal connector, Wide Temp.
