EMP2-X801
PCIe 2.0 compliant. RS-232/422/485 mode configurable by software
4800 to 3Mbps serial data rate (RS-232 921.6Kbps) serial data rate. 16C550 compatible. 256-byte FIFOs
Industrial temperature(-40 ºC to 85 ºC) operation
Flexible design with cable and daug
EMP2-X801
产品特色
- PCIe 2.0 compliant. RS-232/422/485 mode configurable by software
- 4800 to 3Mbps serial data rate (RS-232 921.6Kbps) serial data rate. 16C550 compatible. 256-byte FIFOs
- Industrial temperature(-40 ºC to 85 ºC) operation
- Flexible design with cable and daughter board x 8 (DB-9 connectors)
- Termination Resistor and 5V/12V output by jumper setting on daughterboard
- ESD(Electrostatic Discharge) protection circuit to prevent system damage
- 30μ” golden finger, 3-year warranty
- Industrial design, manufactured in innodisk Taiwan
规格：
| Module Name | EMP2-X801 |
| Module Type | mPCIe to eight RS-232/422/485 Module |
| Function | Serial |
| Form Factor | mPCIe |
| Input I/F | PCI Express 2.0 x 1 |
| Output I/F | RS-232/422/485 |
| Output connector | DB-9 x 8 |
| TDP | 0.478W (3.3V x 145mA) |
| Dimensions (W x L x H/mm) | 30 x 50.9 x 8.45 |
| Temperature | Operation: W/T temp: -40°C ~ +85°C Storage: -55°C ~ +95°C |
| Environment | Vibration: 5G @7~2000Hz Shock: 50G @ 0.5ms |
| Notes | Please download driver from MyInnodisk website. Windows: XP(32 bit), 7(32/64 bit), 8/8.1(32/64 bit), 10, WES7, CE7.0 Linux: Kernel 2.6.x and above.(We can provide Linux source for modification.) |
产品料号：
| P/N | Description |
| EMP2-X801-W1(Wide Temp.) | mPCIe to 8 x RS-232/422/485 Module |
