EMP2-X402

PCIe 2.0 compliant. RS-422/485 mode configurable by switch. Supports 485HD (Half Duplex) and 485FD (Full Duplex)
4800 to 3Mbps serial data rate. 16C550 compatible. 256-byte FIFOs
Industrial temperature(-40 ºC to 85 ºC) operation
Flexible design with DB

附件下载

EMP2-X402



产品特色



  • PCIe 2.0 compliant. RS-422/485 mode configurable by switch. Supports 485HD (Half Duplex) and 485FD (Full Duplex)
  • 4800 to 3Mbps serial data rate. 16C550 compatible. 256-byte FIFOs
  • Industrial temperature(-40 ºC to 85 ºC) operation
  • Flexible design with DB-9 connectors and cable
  • Termination Resistor by jumper setting
  • ESD up to 15KV(Electrostatic Discharge) protection circuit to prevent system damage.
  • 30μ" golden finger, 3-year warranty
  • Industrial design, manufactured in innodisk Taiwan






规格:

Module NameEMP2-X402
Module TypemPCIe to 4 x 422/485 Module
FunctionSerial
Form FactormPCIe
Input I/FPCI Express 2.0 x 1
Output I/FRS-422/485
Output connectorDB-9 x 4
TDP0.33W (3.3V x 100mA)
Dimensions (W x L x H/mm)30 x 50.9 x 8.25
TemperatureOperation: STD temp: 0°~70°C
Storage: -55°C ~ +95°C
EnvironmentVibration: 5G @7~2000Hz
Shock: 50G @ 0.5ms
NotesPlease download driver from MyInnodisk website.
Windows: XP(32 bit), 7(32/64 bit), 8/8.1(32/64 bit), 10,
WES7, CE7.0
Linux: Kernel 2.6.x and above. (We can provide Linux source
for modification.)

产品料号:

P/NDescription
EMP2-X402-W1 (Wide Temp.)mPCIe to 4 x 422/485 Module
