EMUI-0D01

32bit digital I/O of 4 port (each port 8bit)
Programmable I/O
Selectable VCCIO 3.3V or 5V by DIP switch
Buffered I/O
- (Output 5V, 32mA source, 32mA sink)
- (Output 3.3V, 24mA source, 24mA sink)
4 external interrupts with rising/falling edge on port

附件下载

EMUI-0D01



产品特色



  • 32bit digital I/O of 4 port (each port 8bit)
  • Programmable I/O
  • Selectable VCCIO 3.3V or 5V by DIP switch
  • Buffered I/O
    - (Output 5V, 32mA source, 32mA sink)
    - (Output 3.3V, 24mA source, 24mA sink)
  • 4 external interrupts with rising/falling edge on port D
  • Keep configuration after hardware reboot
  • Supports 3rd mounting hole and USB Pin header for out-of-minicard installation
  • Complies with EN61000-4-2 (ESD) Air-15kV, Contact-8kV
  • Industrial temperature (-40 ºC to 85 ºC) operation
  • 30μ” golden finger, 3-year warranty
  • Industrial design, manufactured in Innodisk Taiwan






规格:

Module NameEMUI-0D01
Module TypeUSB to 32bit Digital I/O Module
FunctionDIO
Form FactormPCIe
Input I/FUSB 2.0
Output I/F32bit Digital I/O
Output connector40pin 1.25mm (40DP-1.25 ) with DB37 male cable
TDP0.175W (5V x 35mA)
Dimensions (W x L x H/mm)30 x 50.9 x 8.2
TemperatureOperation: W/T temp: -40°C ~ +85°C
Storage: -55°C ~ +95°C
EnvironmentVibration: 5G @7~2000Hz
Shock: 50G @ 0.5ms
NotesPlease download driver and API(C code Library) from
MyInnodisk website.
Windows: XP(32bit), 7(32/64bit), 8/8.1(32/64bit), 10(32/64bit)
Linux: Native CDC-ACM driver
API Supports Windows and Linux.

产品料号:

P/NDescription
EMUI-0D01-W1USB to 32bit Digital I/O Module


EMUI-0D01
32bit digital I/O of 4 port (each port 8bit)
Programmable I/O
Selectable VCCIO 3.3V or 5V by DIP switch
Buffered I/O
- (Output 5V, 32mA source, 32mA sink)
- (Output 3.3V, 24mA source, 24mA sink)
4 external interrupts with rising/falling edge on port
