EGPV-1101
Support display output of HDMI 1.4 or DVI-D, single/dual 24bit LVDS channel
Single HDMI display resolution up to 4K UHD (3840x2160@30p)
Single DVI-D display resolution up to FHD (1920x1080@60p)
Dual LVDS display resolution up to FHD (1920x1080@60p)
Bu
EGPV-1101
产品特色
- Support display output of HDMI 1.4 or DVI-D, single/dual 24bit LVDS channel
- Single HDMI display resolution up to 4K UHD (3840x2160@30p)
- Single DVI-D display resolution up to FHD (1920x1080@60p)
- Dual LVDS display resolution up to FHD (1920x1080@60p)
- Built-in 256MB DDR3 memory.
- Industrial temperature -40ºC to 85ºC
- 30μ” golden finger, 3-year warranty
规格：
| Module Name | EGPV-1101 |
| Module Type | M.2 to Single HDMI or DVI-D Module M.2 to Single/Dual Channel LVDS Module |
| Form Factor | M.2 2280 B-M |
| Input I/F | PCI Express 2.0 x 2 |
| Output I/F | HDMI or DVI-D x 1 Single & Dual LVDS |
| Output connector | P1.25mm 20pin x 1 (HDMI) 20pin x 2 (LVDS) |
| TDP | 2.78W (3.3V, 843mA) |
| Dimensions (W x L x H/mm) | 22 x 80 x 7.1 |
| Temperature | Operation: STD temp: 0°~70°C Storage: -55°C ~ +95°C |
| Environment | Vibration: 20G @7~2000Hz, Shock: 1500G @ 0.5ms |
| Notes | Driver: Win10 32/64, Linux kernel 3.13- 4.15. |
产品料号：
| P/N | Description |
| EGPV-1101-C1 | (Standard Temp.) M.2 to Single HDMI or DVI-D Module |
| EGPV-1101-W1 | (Wide Temp.) M.2 to Single HDMI or DVI-D Module |
| EGPV-1101-C2 | (Standard Temp.) M.2 to Single/Dual Channel LVDS Module |
| EGPV-1101-W2 | (Wide Temp.) M.2 to Single/Dual Channel LVDS Module |
| 7W9000000120 | HDMI Cable |
| 7W9000000130 | DVI Cable |
