EMPV-1202



产品特色



  • VGA Output up to 1920x1080, up to 75Hz vertical rate
  • LVDS resolution supports up to 1600 x 1200
  • EMPV-1202-C1/W1 Support 18 bit panel and 24 bit JEIDA LVDS
  • EMPV-1202-C2/W2 Support 24 bit VESA LVDS
  • Allow for 90º, 180º, and 270º rotation of on-screen images
  • Optional Industrial Temperature (-10°C to +85°C) support
  • 30μ” golden finger, 3 years warranty
  • Industrial design. Manufactured in innodisk Taiwan






规格:

Module NameEMPV-1202
Module TypemPCIe to VGA & 18/24 bit LVDS module
Form FactormPCIe
Input I/FPCI Express 1.0
Output I/FVGA, 18/24 bit LVDS (C1 for JEIDA, C2 for VESA)
Output connector40pin 1.25mm (40DP-1.25)
TDP1.98W(3.3V x 600mA)
Dimensions (W x L x H/mm)ST: 50.95 x 30 x 8.45
WT: 50.95 x 30 x 8.98
TemperatureOperation: STD: 0°C ~ +70°C; WT: -10°C ~ +85°C; Storage: -55°C ~ +95°C
EnvironmentVibration: 5G @7~2000Hz
Shock: 50G @ 0.5ms
NotesNeed to connect external 5V power for LVDS panel.
OS Support : Windows XP (32 bit), Windows 7/8/8.1/10 (32/64 bit),
Linux Ubuntu 12.04-16.04(32/64bit),
Linux Fedora 17- 21(32/64bit),
Linux CentOS/Redhat 6.5 (32/64bit)- 7.2(64bit)
Please download driver from Myinnodisk website.

产品料号:

P/NDescriptionRemark
EMPV-1202-C1(Standard Temp.)mPCIe to VGA & 18 bit panel and 24 bit JEIDA LVDS format module
EMPV-1202-W1(Wide Temp.)mPCIe to VGA & 18 bit panel and 24 bit JEIDA LVDS format module
EMPV-1202-C2(Standard Temp.)mPCIe to VGA & 24 bit VESA LVDS format module
EMPV-1202-W2(Wide Temp.)mPCIe to VGA & 24 bit VESA LVDS format module
